Resistor Networks, Arrays
Resistor networks or arrays are devices of two or more resistors in a single surface mount or through-hole package. The resistors may be isolated from each other or connected in an R2R ladder (digital to analog converter), bussed, voltage divider, dual terminator, digital-to-analog converter, or decade resistor circuit type. Single or multiple resistance values range from zero (jumper) to 5 GΩ and 0.1% to 15% tolerance.
Product List
Total Components: 16
| Product | Pricing | Datasheet | Supplier Device Package | Size / Dimension | Height - Seated (Max) | Circuit Type | Resistance (Ohms) | Tolerance | Number of Resistors | Resistor Matching Ratio | Resistor-Ratio-Drift | Number of Pins | Power Per Element | Temperature Coefficient | Operating Temperature | Applications | Mounting Type | Package / Case | Stock & Quantity |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 1776-C681 Caddock Electronics, Inc. | 1 $19.4600 | Datasheet | - | 1.000" L x 0.110" W (25.40mm x 2.79mm) | 0.550" (13.97mm) | Decade Resistor | 1k, 9k, 90k, 900k, 9M | ±0.1% | 5 | ±0.05% | ±10ppm/°C | 6 | 62.5mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 10-SIP, 6 Leads | 3,980 Cart + RFQ |
1776-C6815 Caddock Electronics, Inc. | 1 $26.5800 | Datasheet | - | 1.000" L x 0.110" W (25.40mm x 2.79mm) | 0.550" (13.97mm) | Decade Resistor | 1k, 9k, 90k, 900k, 9M | ±0.1% | 5 | ±0.05% | ±5ppm/°C | 6 | 62.5mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 10-SIP, 6 Leads | 4,383 Cart + RFQ |
 HVD5-B10M-050-05 Caddock Electronics, Inc. | 1 $39.5900 | Datasheet | - | 1.500" L x 0.110" W (38.10mm x 2.79mm) | 0.610" (15.50mm) | Voltage Divider | 100k, 9.9M | ±0.1% | 2 | ±0.05% | ±5ppm/°C | 6 | 31mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 15-SIP, 6 Leads | 3,730 Cart + RFQ |
1776-C681 Caddock Electronics, Inc. | 1 $19.4600 | Datasheet | - | 1.000" L x 0.110" W (25.40mm x 2.79mm) | 0.550" (13.97mm) | Decade Resistor | 1k, 9k, 90k, 900k, 9M | ±0.1% | 5 | ±0.05% | ±10ppm/°C | 6 | 62.5mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 10-SIP, 6 Leads | 5,136 Cart + RFQ |
1776-C6815 Caddock Electronics, Inc. | 1 $26.5800 | Datasheet | - | 1.000" L x 0.110" W (25.40mm x 2.79mm) | 0.550" (13.97mm) | Decade Resistor | 1k, 9k, 90k, 900k, 9M | ±0.1% | 5 | ±0.05% | ±5ppm/°C | 6 | 62.5mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 10-SIP, 6 Leads | 2,594 Cart + RFQ |
HVD5-B10M-050-05 Caddock Electronics, Inc. | 1 $39.5900 | Datasheet | - | 1.500" L x 0.110" W (38.10mm x 2.79mm) | 0.610" (15.50mm) | Voltage Divider | 100k, 9.9M | ±0.1% | 2 | ±0.05% | ±5ppm/°C | 6 | 31mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 15-SIP, 6 Leads | 3,077 Cart + RFQ |
HVD5-A50M-050-05 Caddock Electronics, Inc. | 1 $67.4800 | Datasheet | - | 1.500" L x 0.110" W (38.10mm x 2.79mm) | 0.610" (15.50mm) | Voltage Divider | 50k, 49.95M | ±0.1% | 2 | ±0.05% | ±5ppm/°C | 6 | 31mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 15-SIP, 6 Leads | 3,402 Cart + RFQ |
HVD5-A10M-050-05 Caddock Electronics, Inc. | 1 $39.5900 | Datasheet | - | 1.500" L x 0.110" W (38.10mm x 2.79mm) | 0.610" (15.50mm) | Voltage Divider | 10k, 9.99M | ±0.1% | 2 | ±0.05% | ±5ppm/°C | 6 | 31mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 15-SIP, 6 Leads | 2,794 Cart + RFQ |
1776-C48 Caddock Electronics, Inc. | 1 $13.5744 | Datasheet | - | 1.200" L x 0.110" W (30.48mm x 2.79mm) | 0.550" (13.97mm) | Decade Resistor | 1k, 10k, 101k, 1M, 10M | ±0.1% | 5 | ±0.1% | ±10ppm/°C | 7 | 62.5mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 12-SIP, 7 Leads | 9,496 Cart + RFQ |
1776-C481 Caddock Electronics, Inc. | 1 $16.7816 | Datasheet | - | 1.200" L x 0.110" W (30.48mm x 2.79mm) | 0.550" (13.97mm) | Decade Resistor | 1k, 10k, 101k, 1M, 10M | ±0.1% | 5 | ±0.05% | ±10ppm/°C | 7 | 62.5mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 12-SIP, 7 Leads | 5,567 Cart + RFQ |
HVD5-A20M-050-05 Caddock Electronics, Inc. | 1 $50.6200 | Datasheet | - | 1.500" L x 0.110" W (38.10mm x 2.79mm) | 0.610" (15.50mm) | Voltage Divider | 20k, 19.98M | ±0.1% | 2 | ±0.05% | ±5ppm/°C | 6 | 31mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 15-SIP, 6 Leads | 2,660 Cart + RFQ |
HVD5-B20M-050-05 Caddock Electronics, Inc. | 1 $50.6200 | Datasheet | - | 1.500" L x 0.110" W (38.10mm x 2.79mm) | 0.610" (15.50mm) | Voltage Divider | 200k, 19.8M | ±0.1% | 2 | ±0.05% | ±5ppm/°C | 6 | 31mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 15-SIP, 6 Leads | 3,433 Cart + RFQ |
1776-C4815 Caddock Electronics, Inc. | 1 $22.9128 | Datasheet | - | 1.200" L x 0.110" W (30.48mm x 2.79mm) | 0.550" (13.97mm) | Decade Resistor | 1k, 10k, 101k, 1M, 10M | ±0.1% | 5 | ±0.05% | ±5ppm/°C | 7 | 62.5mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 12-SIP, 7 Leads | 4,774 Cart + RFQ |
USVD2-A10M-010-02 Caddock Electronics, Inc. | 1 $58.8486 | Datasheet | - | 1.500" L x 0.155" W (38.10mm x 3.94mm) | 0.520" (13.21mm) | Voltage Divider | 10k, 9.99M | ±0.1% | 2 | ±0.01% | ±2ppm/°C | 4 | 100mW | ±10ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 4-SIP Variation | 8,680 Cart + RFQ |
HVD5-B50M-050-05 Caddock Electronics, Inc. | 1 $67.4800 | Datasheet | - | 1.500" L x 0.110" W (38.10mm x 2.79mm) | 0.610" (15.50mm) | Voltage Divider | 500k, 49.5M | ±0.1% | 2 | ±0.05% | ±5ppm/°C | 6 | 31mW | ±30ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 15-SIP, 6 Leads | 3,030 Cart + RFQ |
USVD2-B10M-010-02 Caddock Electronics, Inc. | 1 $76.2900 | Datasheet | - | 1.500" L x 0.155" W (38.10mm x 3.94mm) | 0.520" (13.21mm) | Voltage Divider | 100k, 9.9M | ±0.1% | 2 | ±0.01% | ±2ppm/°C | 4 | 100mW | ±10ppm/°C | -40°C ~ 85°C | Voltage Divider (TCR Matched) | Through Hole | 4-SIP Variation | 7,828 Cart + RFQ |
