RF Multiplexers
RF Multiplexers use bi-directional bandpass filters to combine RF signals for transmission through a single coaxial cable or to split a combined signal into separate signals for transmission through independent coax cables. Types of multiplexing include diplexing, duplexing. triplexing, quadplexing and quintplexing. Multiplexors are differentiated by their frequency bands, low band attenuation, high band attenuation, return loss and mounting type.
Product List
Total Components: 2
ProductPricingDatasheetTypeFrequency Bands (Low / High)Low Band Attenuation (min / max dB)High Band Attenuation (min / max dB)Return Loss (Low Band / High Band)Mounting TypePackage / CaseStock & Quantity
MAFL-011077
MACOM Technology Solutions
1
$12.2600
Datasheet
Diplexer5MHz ~ 85MHz / 102MHz ~ 1.218GHz--24.0dB / 24.0dBSurface Mount20-SMD, No Lead
9,614
Cart +
RFQ
MAFL-011078
MACOM Technology Solutions
1
$12.2600
Datasheet
Diplexer5MHz ~ 42MHz / 54MHz ~ 1.218GHz--24.0dB / 24.0dBSurface Mount20-SMD, No Lead
7,255
Cart +
RFQ
