Balun
A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.
Product List
Total Components: 100
| Product | Pricing | Datasheet | Frequency Range | Impedance - Unbalanced/Balanced | Phase Difference | Insertion Loss (Max) | Return Loss (Min) | Package / Case | Mounting Type | Stock & Quantity |
|---|---|---|---|---|---|---|---|---|---|---|
 DEA102500LT-9052A1 TDK Corporation | 1 $0.2500 | Datasheet | 2.3GHz ~ 2.5GHz | 50 / -Ohm | 178° | 0.9dB | 15dB | 0402 (1005 Metric), 4 PC Pad | Surface Mount | 3,879 Cart + RFQ |
 2450BL15B100E Johanson Technology | 1 $0.3500 | Datasheet | 2.4GHz ~ 2.5GHz | 50 / 100Ohm | 180° ±10° | 1.0dB | 9.5dB | 0805 (2012 Metric) | Surface Mount | 1,603 Cart + RFQ |
 0900BL18B100E Johanson Technology | 1 $0.5571 100 $0.4457 500 $0.3714 | Datasheet | 800MHz ~ 1GHz | 50 / 100Ohm | 180° ±10° | 1.0dB | 9.5dB | 1206 (3216 Metric) | Surface Mount | 1,238 Cart + RFQ |
 0850BM14E0016T Johanson Technology | 1 $0.4400 | Datasheet | 770MHz ~ 928MHz | 50 / 50Ohm | 180° ±15° | 1.8dB | 9.5dB | 0603 (1608 Metric) | Surface Mount | 7,083 Cart + RFQ |
 HHM1595A1 TDK Corporation | 1 $0.5900 | Datasheet | 3GHz ~ 8GHz | 50 / 100Ohm | 180° ±20° | 1.5dB | 8dB | 0805 (2012 Metric) | Surface Mount | 3,282 Cart + RFQ |
2450BM14G0011T Johanson Technology | 1 $0.5000 | Datasheet | 2.4GHz ~ 2.5GHz | 50 / -Ohm | 180° ±10° | 1.5dB | 9.5dB | 0603 (1608 Metric) | Surface Mount | 3,160 Cart + RFQ |
 BAL-NRF01D3 STMicroelectronics | 1 $0.6800 | Datasheet | 2.4GHz ~ 2.54GHz | 50 / -Ohm | 3° | 2.25dB | 10dB | 5-WFBGA, FCBGA | Surface Mount | 4,954 Cart + RFQ |
 1720BL15B0050E Johanson Technology | 1 $0.6800 | Datasheet | 625MHz ~ 2.8GHz | 50 / 50Ohm | 180° ±10° | 1.5dB | 9.5dB | 0805 (2012 Metric) | Surface Mount | 5,293 Cart + RFQ |
1720BL15A0100E Johanson Technology | 1 $0.6800 | Datasheet | 625MHz ~ 2.8GHz | 50 / 100Ohm | 180° ±10° | 1.5dB | 9.5dB | 0805 (2012 Metric) | Surface Mount | 1,602 Cart + RFQ |
 ATB2012-50011-T000 TDK Corporation | 1 $0.7000 | Datasheet | 40MHz ~ 860MHz | 50 / 50Ohm | - | 2.5dB | - | 0805 (2012 Metric) | Surface Mount | 9,130 Cart + RFQ |
 BD0810J50100AHF Anaren Wireless / TTM Technologies | 1 $0.9000 | Datasheet | 800MHz ~ 1GHz | 50 / 100Ohm | 1° | 0.95dB | 13dB | 0805 (2012 Metric) | Surface Mount | 3,845 Cart + RFQ |
BD1631J50100AHF Anaren Wireless / TTM Technologies | 1 $2.2815 100 $1.8252 500 $1.5210 | Datasheet | 1.6GHz ~ 3.1GHz | 50 / 100Ohm | 2.3° | 0.9dB | 10dB | 0805 (2012 Metric) | Surface Mount | 4 Cart + RFQ |
BD1222J50200AHF Anaren Wireless / TTM Technologies | 1 $0.9000 | Datasheet | 1.2GHz ~ 2.2GHz | 50 / 200Ohm | 2° | 0.4dB | -18dB | 0805 (2012 Metric) | Surface Mount | 4,638 Cart + RFQ |
 2450BM14G0011T-AEC Johanson Technology | 1 $0.6000 | Datasheet | 2.4GHz ~ 2.5GHz | 50 / -Ohm | 180° ±10 | 1.8dB | 9.5dB | 0603 (1608 Metric), 6 PC Pad | Surface Mount | 4,689 Cart + RFQ |
 BALF-SPI2-01D3 STMicroelectronics | 1 $0.8200 | Datasheet | 868MHz ~ 928MHz | 50 / 50Ohm | 7° | 2.1dB | 10dB | 6-UFBGA, FCBGA | Surface Mount | 8,531 Cart + RFQ |
 0900BL15C050E Johanson Technology | 1 $0.8000 | Datasheet | 800MHz ~ 1GHz | 50 / 50Ohm | 180° ±10° | 1.2dB | 9.5dB | 0805 (2012 Metric) | Surface Mount | 9,587 Cart + RFQ |
2450BM15A0002E Johanson Technology | 1 $0.3075 100 $0.2460 500 $0.2050 | Datasheet | 2.4GHz ~ 2.5GHz | 50 / -Ohm | 180° ±15° | 1.5dB | 10dB | 0805 (2012 Metric) | Surface Mount | 3,500 Cart + RFQ |
 BD3150N50100AHF Anaren Wireless / TTM Technologies | 1 $0.8000 | Datasheet | 3.1GHz ~ 5GHz | 50 / 100Ohm | 3° | 0.9dB | 13dB | 0404 (1010 Metric) | Surface Mount | 4,960 Cart + RFQ |
2450BM14E0003T Johanson Technology | 1 $0.6600 | Datasheet | 2.4GHz ~ 2.5GHz | 50 / -Ohm | 150° ±15° | 2.5dB | 9.5dB | 0603 (1608 Metric), 6 PC Pad | Surface Mount | 4,770 Cart + RFQ |
 0900PC15A0036E Johanson Technology | 1 $0.6900 | Datasheet | 862MHz ~ 928MHz, 2.4GHz ~ 2.5GHz | 50 / 50Ohm | 180° ±15° | 1.6dB, 2.0dB | 10dB | 0805 (2012 Metric), 10 PC Pad | Surface Mount | 7,968 Cart + RFQ |
