Magnetic Wire
Magnet wire products are characterized by their solid cross sections and very thin insulation, consisting of a varnish-like layer of polyamide, polyurethane or similar polymer material. It is used primarily in the construction of electromagnetic devices such as transformers, inductors, motors, solenoids, and similar devices, where its characteristically thin insulation enables increased winding density and better thermal transfer compared to wire types with thicker insulation systems.
Product List
Total Components: 100
Product | Pricing | Datasheet | Wire Gauge | Conductor Material | Jacket (Insulation) Material | Jacket (Insulation) Diameter | Length - Approximate | Ratings | Stock & Quantity |
---|---|---|---|---|---|---|---|---|---|
600214 CnC Tech | 1 $106.9000 | Datasheet | 14 AWG | Copper, Annealed Bare | Polyamide | 0.068" (1.73mm) | 177.1' (54m) | MW 35-C HY | 4,430 Cart + RFQ |
600218 CnC Tech | 1 $109.4100 | Datasheet | 18 AWG | Copper, Annealed Bare | Polyamide | 0.043" (1.09mm) | 448' (136.6m) | MW 35-C HY | 1,838 Cart + RFQ |
8052 Belden | 1 $84.4600 | Datasheet | 24 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.022" (0.55mm) | 404.0' (123m) | MW 28-C SL | 3,899 Cart + RFQ |
8053 Belden | 1 $86.5400 | Datasheet | 26 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.017" (0.43mm) | 645.0' (197m) | MW 28-C SL | 3,981 Cart + RFQ |
8054 Belden | 1 $89.6500 | Datasheet | 28 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.014" (0.36mm) | 1020.0' (311m) | MW 28-C SL | 7,211 Cart + RFQ |
8055 Belden | 1 $98.2900 | Datasheet | 30 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.011" (0.28mm) | 1615.0' (492m) | MW 28-C SL | 5,113 Cart + RFQ |
600216 CnC Tech | 1 $107.9200 | Datasheet | 16 AWG | Copper, Annealed Bare | Polyamide | 0.054" (1.37mm) | 282.4' (86.1m) | MW 35-C HY | 2,930 Cart + RFQ |
610214 CnC Tech | 1 $109.1500 | Datasheet | 14 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.067" (1.70mm) | 177.1' (54m) | MW 28-C SL | 7,315 Cart + RFQ |
600224 CnC Tech | 1 $110.6200 | Datasheet | 24 AWG | Copper, Annealed Bare | Polyamide | 0.023" (0.58mm) | 1799.1' (548.5m) | MW 35-C HY | 8,782 Cart + RFQ |
610226 CnC Tech | 1 $115.1500 | Datasheet | 26 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.017" (0.43mm) | 2878.2' (877.5m) | MW 28-C SL | 2,967 Cart + RFQ |
600228 CnC Tech | 1 $115.4200 | Datasheet | 28 AWG | Copper, Annealed Bare | Polyamide | 0.015" (0.38mm) | 4587.4' (1398.6m) | MW 35-C HY | 5,489 Cart + RFQ |
600230 CnC Tech | 1 $118.3600 | Datasheet | 30 AWG | Copper, Annealed Bare | Polyamide | 0.012" (0.31mm) | 7281.3' (2219.9m) | MW 35-C HY | 8,543 Cart + RFQ |
610232 CnC Tech | 1 $119.2500 | Datasheet | 32 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.009" (0.23mm) | 11399.6' (3475.5m) | MW 28-C SL | 7,252 Cart + RFQ |
600232 CnC Tech | 1 $119.6100 | Datasheet | 32 AWG | Copper, Annealed Bare | Polyamide | 0.010" (0.25mm) | 11399.6' (3475.5m) | MW 35-C HY | 9,629 Cart + RFQ |
610228 CnC Tech | 1 $123.6900 | Datasheet | 28 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.014" (0.36mm) | 4587.4' (1398.6m) | MW 28-C SL | 7,390 Cart + RFQ |
8058 Belden | 1 $126.7000 | Datasheet | 36 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.006" (0.16mm) | 6397.6' (1950m) | MW 28-C SL | 7,064 Cart + RFQ |
8073 Belden | 1 $138.3500 | Datasheet | 14 AWG | Copper, Annealed Bare | Polyamide | 0.068" (1.73mm) | 80.0' (24m) | MW 35-C HY | 3,150 Cart + RFQ |
8051 Belden | 1 $82.9400 | Datasheet | 22 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.027" (0.69mm) | 254.0' (77m) | MW 28-C SL | 2,558 Cart + RFQ |
8056 Belden | 1 $107.4600 | Datasheet | 32 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.009" (0.23mm) | 2515.0' (767m) | MW 28-C SL | 2,342 Cart + RFQ |
8078 Belden | 1 $146.4200 | Datasheet | 24 AWG | Copper, Annealed Bare | Polyamide | 0.023" (0.58mm) | 793.0' (242m) | MW 35-C HY | 3,038 Cart + RFQ |
