Magnetics - Transformer, Inductor Components
The magnetic component product category includes products used for assembling custom or prototype magnetic components, such as polyurethane- or polyamide-insulated copper wire (magnet wire), gapped and ungapped ferrite cores, and coil formers (bobbins) around which such wire can be wound and subsequently assembled with a core to produce a transformer or inductor with user-controlled characteristics.
Product List
Total Components: 11
| Product | Pricing | Datasheet | Accessory Type | For Use With/Related Products | Supplier Device Package | Core Type | Supplier Device Package | Material | Diameter | Inductance Factor (Al) | Tolerance | Gap | Effective Permeability (µe) | Initial Permeability (µi) | Core Factor (ΣI/A) mm<sup>-1</sup> | Effective Length (le) mm | Effective Area (Ae) mm² | Minimum Core Cross Section (Amin) mm² | Effective Magnetic Volume (Ve) mm³ | Finish | Height | Length | Width | Wire Gauge | Conductor Material | Jacket (Insulation) Material | Jacket (Insulation) Diameter | Length - Approximate | Ratings | Stock & Quantity |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 600214 CnC Tech | 1 $106.9000 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 14 AWG | Copper, Annealed Bare | Polyamide | 0.068" (1.73mm) | 177.1' (54m) | MW 35-C HY | 4,430 Cart + RFQ |
 600218 CnC Tech | 1 $109.4100 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 18 AWG | Copper, Annealed Bare | Polyamide | 0.043" (1.09mm) | 448' (136.6m) | MW 35-C HY | 1,838 Cart + RFQ |
 600216 CnC Tech | 1 $107.9200 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 16 AWG | Copper, Annealed Bare | Polyamide | 0.054" (1.37mm) | 282.4' (86.1m) | MW 35-C HY | 2,930 Cart + RFQ |
610214 CnC Tech | 1 $109.1500 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 14 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.067" (1.70mm) | 177.1' (54m) | MW 28-C SL | 7,315 Cart + RFQ |
 600224 CnC Tech | 1 $110.6200 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 24 AWG | Copper, Annealed Bare | Polyamide | 0.023" (0.58mm) | 1799.1' (548.5m) | MW 35-C HY | 8,782 Cart + RFQ |
 610226 CnC Tech | 1 $115.1500 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 26 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.017" (0.43mm) | 2878.2' (877.5m) | MW 28-C SL | 2,967 Cart + RFQ |
 600228 CnC Tech | 1 $115.4200 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 28 AWG | Copper, Annealed Bare | Polyamide | 0.015" (0.38mm) | 4587.4' (1398.6m) | MW 35-C HY | 5,489 Cart + RFQ |
 600230 CnC Tech | 1 $118.3600 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 30 AWG | Copper, Annealed Bare | Polyamide | 0.012" (0.31mm) | 7281.3' (2219.9m) | MW 35-C HY | 8,543 Cart + RFQ |
610232 CnC Tech | 1 $119.2500 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 32 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.009" (0.23mm) | 11399.6' (3475.5m) | MW 28-C SL | 7,252 Cart + RFQ |
 600232 CnC Tech | 1 $119.6100 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 32 AWG | Copper, Annealed Bare | Polyamide | 0.010" (0.25mm) | 11399.6' (3475.5m) | MW 35-C HY | 9,629 Cart + RFQ |
610228 CnC Tech | 1 $123.6900 | Datasheet | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 28 AWG | Copper, Annealed Bare | Polyurethane (PU) | 0.014" (0.36mm) | 4587.4' (1398.6m) | MW 28-C SL | 7,390 Cart + RFQ |
