Card Racks
Items in the card rack family (also known as sub-racks) are enclosure-like products designed to established dimensional standards that provide a mechanical means of assembling large, complex systems in a modular fashion. They provide a means by which multiple circuit boards or similar equipment components can be assembled together in a modular form, which can subsequently be mounted together with other such modularized equipment in a similar, larger enclosure known as a rack.
Product List
Total Components: 432
Product | Pricing | Datasheet | Type | Size / Dimension | Height | Card Size Range | Guide Method | Material | Stock & Quantity |
---|---|---|---|---|---|---|---|---|---|
CCM15S/90 Vector Electronics & Technology, Inc. | 1 $241.1700 | Datasheet | Assembled Card Mount Subracks | 12.000" L x 19.000" W (304.80mm x 482.60mm) | 4U = 7.000" (177.80mm) | 6.250" H x 9.600" L (158.75mm x 243.84mm) | No Card Guide | Aluminum | 2,015 Cart + RFQ |
CCK13S/90 Vector Electronics & Technology, Inc. | 1 $172.5200 | Datasheet | Subrack Kit | 9.000" L x 19.000" W (228.60mm x 482.60mm) | 3U = 5.250" (133.35mm) | 2.500" ~ 4.500" H x 6.500" L (63.50mm ~ 114.30mm x 165.10mm) | Card Guide | Aluminum | 7,545 Cart + RFQ |
24563143 nVent Schroff | 1 $279.4300 | Datasheet | Subrack Kit | 11.614" L x 16.800" W (295.00mm x 426.72mm) | 3U = 5.250" (133.35mm) | - | No Card Guide | Aluminum | 3,680 Cart + RFQ |
24563131 nVent Schroff | 1 $88.8200 | Datasheet | Subrack Kit | 6.890" L x 16.800" W (175.00mm x 426.72mm) | 3U = 5.250" (133.35mm) | - | No Card Guide | Aluminum | 3,766 Cart + RFQ |
24563431 nVent Schroff | 1 $128.5800 | Datasheet | Subrack Kit | 6.890" L x 16.800" W (175.00mm x 426.72mm) | 6U = 10.500" (266.70mm) | - | No Card Guide | Aluminum | 6,790 Cart + RFQ |
24563432 nVent Schroff | 1 $135.4100 | Datasheet | Subrack Kit | 9.187" L x 16.800" W (235.00mm x 426.72mm) | 6U = 10.500" (266.70mm) | - | No Card Guide | Aluminum | 3,653 Cart + RFQ |
CCA13S/90 Vector Electronics & Technology, Inc. | 1 $186.6500 | Datasheet | Assembled Subracks with Card Guides | 9.000" L x 19.000" W (228.60mm x 482.60mm) | 3U = 5.250" (133.35mm) | 2.500" ~ 4.500" H x 6.500" L (63.50mm ~ 114.30mm x 165.10mm) | Card Guide | Aluminum | 5,896 Cart + RFQ |
CCM13S/90 Vector Electronics & Technology, Inc. | 1 $225.4600 | Datasheet | Assembled Card Mount Subracks | 9.000" L x 19.000" W (228.60mm x 482.60mm) | 3U = 5.250" (133.35mm) | 4.500" H x 6.500" L (114.30mm x 165.10mm) | No Card Guide | Aluminum | 8,520 Cart + RFQ |
CCA17S/90 Vector Electronics & Technology, Inc. | 1 $226.2100 | Datasheet | Assembled Subracks with Card Guides | 12.000" L x 19.000" W (304.80mm x 482.60mm) | 5U = 8.750" (222.25mm) | 6.000" ~ 8.000" H x 9.600" L (152.40mm ~ 203.20mm x 243.84mm) | Card Guide | Aluminum | 5,912 Cart + RFQ |
24563144 nVent Schroff | 1 $288.7100 | Datasheet | Subrack Kit | 13.976" L x 16.800" W (355.00mm x 426.72mm) | 3U = 5.250" (133.35mm) | - | No Card Guide | Aluminum | 3,001 Cart + RFQ |
24563152 nVent Schroff | 1 $318.2800 | Datasheet | Subrack Kit | 9.187" L x 16.800" W (235.00mm x 426.72mm) | 3U = 5.250" (133.35mm) | - | No Card Guide | Aluminum | 5,269 Cart + RFQ |
CM45A65-2 Vector Electronics & Technology, Inc. | 1 $34.5600 | Datasheet | Card Mount Module | 6.570" L x 2.000" W (166.88mm x 50.80mm) | 3U = 5.250" (133.35mm) | 4.500" H x 6.500" L (114.30mm x 165.10mm) | - | Aluminum | 7,343 Cart + RFQ |
CM45A65-4 Vector Electronics & Technology, Inc. | 1 $39.0800 | Datasheet | Card Mount Module | 6.570" L x 4.000" W (166.88mm x 101.60mm) | 3U = 5.250" (133.35mm) | 4.500" H x 6.500" L (114.30mm x 165.10mm) | - | Aluminum | 1,910 Cart + RFQ |
24563133 nVent Schroff | 1 $96.4000 | Datasheet | Subrack Kit | 11.614" L x 16.800" W (295.00mm x 426.72mm) | 3U = 5.250" (133.35mm) | - | No Card Guide | Aluminum | 4,523 Cart + RFQ |
24563436 nVent Schroff | 1 $148.9900 | Datasheet | Subrack Kit | 18.701" L x 16.800" W (475.00mm x 426.72mm) | 6U = 10.500" (266.70mm) | - | No Card Guide | Aluminum | 6,882 Cart + RFQ |
3684045 Wakefield Thermal | 1 $153.2100 | Datasheet | Subrack Frame | 9.646" L x 16.800" W (245.00mm x 426.72mm) | 6U = 10.500" (266.70mm) | - | No Card Guide | Aluminum | 1,842 Cart + RFQ |
CCK12S/90 Vector Electronics & Technology, Inc. | 1 $172.5200 | Datasheet | Subrack Kit | 9.000" L x 19.000" W (228.60mm x 482.60mm) | 3U = 5.250" (133.35mm) | 2.500" ~ 4.500" H x 4.500" L (63.50mm ~ 114.30mm x 114.30mm) | Card Guide | Aluminum | 5,564 Cart + RFQ |
CCA28-84-00 Vector Electronics & Technology, Inc. | 1 $181.3300 | Datasheet | Assembled Subracks with Card Guides | 10.000" L x 19.000" W (254.00mm x 482.60mm) | 6U = 10.500" (266.70mm) | 9.187" H x 8.660" L (233.35mm x 219.96mm) | Guide Plate | Aluminum | 3,296 Cart + RFQ |
3684128 Wakefield Thermal | 1 $225.3400 | Datasheet | Subrack Frame | 9.646" L x 16.800" W (245.00mm x 426.72mm) | 3U = 5.250" (133.35mm) | - | No Card Guide | Aluminum | 7,789 Cart + RFQ |
24563157 nVent Schroff | 1 $295.0900 | Datasheet | Subrack Kit | 10.827" L x 16.800" W (275.00mm x 426.72mm) | 3U = 5.250" (133.35mm) | - | No Card Guide | Aluminum | 1,055 Cart + RFQ |
