Transistors - IGBTs - Arrays
Insulated-gate bipolar transistors (IGBTs) are high efficiency and fast switching three-terminal power semiconductor devices primarily used as electronic switches. They are used in switching power supplies in high power applications such as variable-frequency drives (VFDs), electric cars, trains, lamp ballasts, and air-conditioners as well as in switching amplifiers -- sound systems and industrial control systems. IGBT arrays contain multiple devices in one package in full- or half-bridge configurations.
Product List
Total Components: 18
| Product | Pricing | Datasheet | Package / Case | Supplier Device Package | IGBT Type | Configuration | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Power - Max | Vce(on) (Max) @ Vge, Ic | Current - Collector Cutoff (Max) | Input Capacitance (Cies) @ Vce | Input | NTC Thermistor | Operating Temperature | Mounting Type | Stock & Quantity |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MMIX4B20N300 Hamlin / Littelfuse | 1 $102.2800 | Datasheet | 24-SMD Module, 9 Leads | 24-SMPD | - | Full Bridge | 3000 V | 34 A | 150 W | 3.2V @ 15V, 20A | - | - | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 2,739 Cart + RFQ |
MMIX4G20N250 Hamlin / Littelfuse | 1 $81.5200 | Datasheet | 24-SMD Module, 9 Leads | 24-SMPD | - | Half Bridge | 2500 V | 23 A | 100 W | 3.1V @ 15V, 20A | 10 µA | 1.19 nF @ 15 V | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 4,085 Cart + RFQ |
MMIX4B22N300 Hamlin / Littelfuse | 1 $118.6900 | Datasheet | 24-SMD Module, 9 Leads | 24-SMPD | - | Full Bridge | 3000 V | 38 A | 150 W | 2.7V @ 15V, 22A | 35 µA | 2.2 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 2,211 Cart + RFQ |
IXA20PG1200DHG-TRR Hamlin / Littelfuse | 1 $10.5486 | Datasheet | 9-SMD Module | ISOPLUS-SMPD™.B | PT | Half Bridge | 1200 V | 32 A | 130 W | 2.1V @ 15V, 15A | 125 µA | - | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 6,799 Cart + RFQ |
IXA40RG1200DHG-TRR Hamlin / Littelfuse | 1 $12.0998 | Datasheet | 9-SMD Module | ISOPLUS-SMPD™.B | PT | Half Bridge | 1200 V | 63 A | 230 W | 2.15V @ 15V, 35A | 150 µA | - | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 8,364 Cart + RFQ |
IXA20PG1200DHG-TUB Hamlin / Littelfuse | 1 $13.4595 | Datasheet | 9-SMD Module | ISOPLUS-SMPD™.B | PT | Half Bridge | 1200 V | 32 A | 130 W | 2.1V @ 15V, 15A | 125 µA | - | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 2,421 Cart + RFQ |
IXA30PG1200DHG-TRR Hamlin / Littelfuse | 1 $13.6600 | Datasheet | 9-SMD Module | ISOPLUS-SMPD™.B | PT | Half Bridge | 1200 V | 43 A | 150 W | 2.2V @ 15V, 25A | 2.1 mA | - | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 4,014 Cart + RFQ |
IXA40RG1200DHG-TUB Hamlin / Littelfuse | 1 $13.8020 | Datasheet | 9-SMD Module | ISOPLUS-SMPD™.B | PT | Half Bridge | 1200 V | 63 A | 230 W | 2.15V @ 15V, 35A | 150 µA | - | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 2,808 Cart + RFQ |
IXA40PG1200DHG-TUB Hamlin / Littelfuse | 1 $15.4025 | Datasheet | 9-SMD Module | ISOPLUS-SMPD™.B | PT | Half Bridge | 1200 V | 63 A | 230 W | 2.15V @ 15V, 35A | 150 µA | - | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 9,999 Cart + RFQ |
IXA40PG1200DHG-TRR Hamlin / Littelfuse | 1 $15.5784 | Datasheet | 9-SMD Module | ISOPLUS-SMPD™.B | PT | Half Bridge | 1200 V | 63 A | 230 W | 2.15V @ 15V, 35A | 150 µA | - | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 4,573 Cart + RFQ |
IXA30PG1200DHG-TUB Hamlin / Littelfuse | 1 $16.2790 | Datasheet | 9-SMD Module | ISOPLUS-SMPD™.B | PT | Half Bridge | 1200 V | 43 A | 150 W | 2.2V @ 15V, 25A | 2.1 mA | - | Standard | No | -55°C ~ 150°C (TJ) | Surface Mount | 9,866 Cart + RFQ |
 FII40-06D Hamlin / Littelfuse | Datasheet | i4-Pac™-5 | ISOPLUS i4-PAC™ | NPT | Half Bridge | 600 V | 40 A | 125 W | 2.2V @ 15V, 25A | 600 µA | 1.6 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Through Hole | 7,614 Cart + RFQ | |
FII24N17AH1 Hamlin / Littelfuse | Datasheet | i4-Pac™-5 | ISOPLUS i4-PAC™ | NPT | Half Bridge | 1700 V | 18 A | 140 W | 6V @ 15V, 16A | 100 µA | 2.4 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Through Hole | 7,472 Cart + RFQ | |
FII24N17AH1S Hamlin / Littelfuse | Datasheet | i4-Pac™-5 | ISOPLUS i4-PAC™ | NPT | Half Bridge | 1700 V | 18 A | 140 W | 6V @ 15V, 16A | 100 µA | 2.4 nF @ 25 V | Standard | No | - | Through Hole | 4,516 Cart + RFQ | |
FII30-06D Hamlin / Littelfuse | Datasheet | i4-Pac™-5 | ISOPLUS i4-PAC™ | NPT | Half Bridge | 600 V | 30 A | 100 W | 2.4V @ 15V, 20A | 600 µA | 1.1 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Through Hole | 8,167 Cart + RFQ | |
FII30-12E Hamlin / Littelfuse | Datasheet | i4-Pac™-5 | ISOPLUS i4-PAC™ | NPT | Half Bridge | 1200 V | 33 A | 150 W | 2.9V @ 15V, 20A | 200 µA | 1.2 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Through Hole | 8,286 Cart + RFQ | |
FII50-12E Hamlin / Littelfuse | Datasheet | i4-Pac™-5 | ISOPLUS i4-PAC™ | NPT | Half Bridge | 1200 V | 50 A | 200 W | 2.6V @ 15V, 30A | 400 µA | 2 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Through Hole | 6,929 Cart + RFQ | |
FII24N170AH1 Hamlin / Littelfuse | Datasheet | i4-Pac™-4, Isolated | ISOPLUS i4-PAC™ | NPT | Half Bridge | 1700 V | 18 A | 140 W | 6V @ 15V, 16A | 100 µA | 2.4 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Through Hole | 8,786 Cart + RFQ |
