Transistors - FETs, MOSFETs - Single
Discrete Field Effect Transistors (FETs) are widely used in power conversion, motor control, solid-state lighting, and other applications where their characteristic ability to be switched on & off at high frequencies while carrying substantial amounts of current is advantageous. They are used almost universally for applications requiring voltage ratings of a few hundred volts or less, above which other device types such as IGBTs become more competitive.
Product List
Total Components: 535
| Product | Pricing | Datasheet | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Mounting Type | Supplier Device Package | Package / Case | Stock & Quantity |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 PJA3401A_R1_00001 PANJIT | 1 $0.3800 | Datasheet | P-Channel | MOSFET (Metal Oxide) | 30 V | 3.6A (Ta) | 2.5V, 10V | 54mOhm @ 3.6A, 10V | 1.3V @ 250µA | 19 nC @ 10 V | ±12V | 994 pF @ 15 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 4,554 Cart + RFQ |
 PJE8408_R1_00001 PANJIT | 1 $0.4300 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 20 V | 500mA (Ta) | 1.2V, 4.5V | 400mOhm @ 500mA, 4.5V | 900mV @ 250µA | 1.4 nC @ 4.5 V | ±10V | 67 pF @ 10 V | - | 300mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-523 Flat Leads | SC-89, SOT-490 | 5,172 Cart + RFQ |
2N7002KW-AU_R1_000A1 PANJIT | 1 $0.0196 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 60 V | 250mA (Ta) | 4.5V, 10V | 3Ohm @ 500mA, 10V | 2.5V @ 250µA | 0.8 nC @ 5 V | ±20V | 24 pF @ 25 V | - | 350mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-323 | SC-70, SOT-323 | 100,000 Cart + RFQ |
PJA138K-AU_R1_000A1 PANJIT | 1 $0.2700 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 50 V | 500mA (Ta) | 2.5V, 10V | 1.6Ohm @ 500mA, 10V | 1.5V @ 250µA | 1 nC @ 4.5 V | ±20V | 50 pF @ 25 V | - | 500mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 8,496 Cart + RFQ |
PJA3433-AU_R1_000A1 PANJIT | 1 $0.3500 | Datasheet | P-Channel | MOSFET (Metal Oxide) | 30 V | 1.1A (Ta) | 1.8V, 4.5V | 370mOhm @ 1.1A, 4.5V | 1.3V @ 250µA | 1.6 nC @ 4.5 V | ±8V | 125 pF @ 15 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 6,316 Cart + RFQ |
PJA3436-AU_R1_000A1 PANJIT | 1 $0.3500 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 20 V | 1.2A (Ta) | 1.8V, 4.5V | 380mOhm @ 1.2A, 4.5V | 1V @ 250µA | 0.9 nC @ 4.5 V | ±12V | 39 pF @ 10 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 1,210 Cart + RFQ |
PJA3430_R1_00001 PANJIT | 1 $0.3600 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 20 V | 2A (Ta) | 1.8V, 4.5V | 150mOhm @ 2A, 4.5V | 1V @ 250µA | 1.8 nC @ 4.5 V | ±8V | 92 pF @ 10 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 8,795 Cart + RFQ |
2N7002KTB_R1_00001 PANJIT | 1 $0.0196 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 60 V | 115mA (Ta) | 4.5V, 10V | 3Ohm @ 500mA, 10V | 2.5V @ 250µA | 0.8 nC @ 4.5 V | ±20V | 35 pF @ 25 V | - | 200mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-523 Flat Leads | SC-89, SOT-490 | 100,000 Cart + RFQ |
PJA3433_R1_00001 PANJIT | 1 $0.3600 | Datasheet | P-Channel | MOSFET (Metal Oxide) | 30 V | 1.1A (Ta) | 1.8V, 4.5V | 370mOhm @ 1.1A, 4.5V | 1.3V @ 250µA | 1.6 nC @ 4.5 V | ±8V | 125 pF @ 15 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 4,240 Cart + RFQ |
PJA3432_R1_00001 PANJIT | 1 $0.3600 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 30 V | 1.6A (Ta) | 1.8V, 4.5V | 200mOhm @ 1.6A, 4,5V | 1.3V @ 250µA | 1.5 nC @ 4.5 V | ±8V | 93 pF @ 15 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 4,823 Cart + RFQ |
PJA3428_R1_00001 PANJIT | 1 $0.3600 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 30 V | 300mA (Ta) | 1.2V, 4.5V | 1.2Ohm @ 300mA, 4.5V | 1V @ 250µA | 0.9 nC @ 10 V | ±10V | 45 pF @ 10 V | - | 500mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 1,399 Cart + RFQ |
PJC138K-AU_R1_000A1 PANJIT | 1 $0.3600 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 50 V | 360mA (Ta) | 2.5V, 10V | 1.6Ohm @ 500mA, 10V | 1.5V @ 250µA | 1 nC @ 4.5 V | ±20V | 50 pF @ 25 V | - | 236mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-323 | SC-70, SOT-323 | 1,507 Cart + RFQ |
PJE138K_R1_00001 PANJIT | 1 $0.3900 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 50 V | 350mA (Ta) | 2.5V, 10V | 1.6Ohm @ 500mA, 10V | 1.5V @ 250µA | 1 nC @ 4.5 V | ±20V | 50 pF @ 25 V | - | 223mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-523 Flat Leads | SC-89, SOT-490 | 4,705 Cart + RFQ |
PJA3434_R1_00001 PANJIT | 1 $0.3900 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 20 V | 750mA (Ta) | 1.2V, 4.5V | 400mOhm @ 600mA, 4.5V | 1V @ 250µA | 1.4 nC @ 4.5 V | ±10V | 67 pF @ 10 V | - | 500mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 9,143 Cart + RFQ |
PJA3404A_R1_00001 PANJIT | 1 $0.3900 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 30 V | 5.6A (Ta) | 4.5V, 10V | 23mOhm @ 5.6A, 10V | 2.1V @ 250µA | 12.8 nC @ 10 V | ±20V | 602 pF @ 15 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 1,361 Cart + RFQ |
PJA3415A-AU_R1_000A1 PANJIT | 1 $0.3800 | Datasheet | P-Channel | MOSFET (Metal Oxide) | 20 V | 4.5A (Ta) | 1.8V, 4.5V | 48mOhm @ 4.5A, 4.5V | 1.3V @ 250µA | 10 nC @ 4.5 V | ±12V | 980 pF @ 10 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 5,930 Cart + RFQ |
PJC7439-AU_R1_000A1 PANJIT | 1 $0.3800 | Datasheet | P-Channel | MOSFET (Metal Oxide) | 60 V | 250mA (Ta) | 2.5V, 10V | 4Ohm @ 500mA, 10V | 2.5V @ 250µA | 1.1 nC @ 4.5 V | ±20V | 51 pF @ 25 V | - | 350mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-323 | SC-70, SOT-323 | 6,479 Cart + RFQ |
PJA3404_R1_00001 PANJIT | 1 $0.3800 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 30 V | 5.6A (Ta) | 4.5V, 10V | 30mOhm @ 5.6A, 10V | 2.1V @ 250µA | 7.8 nC @ 10 V | ±20V | 343 pF @ 15 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 7,235 Cart + RFQ |
PJA3439_R1_00001 PANJIT | 1 $0.4000 | Datasheet | P-Channel | MOSFET (Metal Oxide) | 60 V | 300mA (Ta) | 2.5V, 10V | 4Ohm @ 500mA, 10V | 2.5V @ 250µA | 1.1 nC @ 4.5 V | ±20V | 51 pF @ 25 V | - | 500mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 2,239 Cart + RFQ |
PJA3436_R1_00001 PANJIT | 1 $0.4000 | Datasheet | N-Channel | MOSFET (Metal Oxide) | 20 V | 1.2A (Ta) | 1.8V, 4.5V | 380mOhm @ 1.2A, 4.5V | 1V @ 250µA | 0.9 nC @ 4.5 V | ±12V | 39 pF @ 10 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | SOT-23 | TO-236-3, SC-59, SOT-23-3 | 8,125 Cart + RFQ |
