Evaluation Boards - LED Drivers
LED Driver Evaluation Boards are a circuit board(s) that are populated with components and used to provide a working example of a specific power circuit or device. The boards in this family provide an example of an LED driver for adjustable blinking, analog brightness, backlight, bipolar switch, boost converter, brightness control, camera flash, dimmable, constant current, and RGB control, plus many more.
Product List
Total Components: 18
| Product | Pricing | Datasheet | Current - Output / Channel | Outputs and Type | Voltage - Output | Features | Voltage - Input | Supplied Contents | Utilized IC / Part | Stock & Quantity |
|---|---|---|---|---|---|---|---|---|---|---|
 DC1831A ADI (Analog Devices, Inc.) | 1 $176.5500 | Datasheet | 10A | 1, Non-Isolated | 10V | - | 12V ~ 60V | Board(s) | LT3763 | 2,025 Cart + RFQ |
 DC2257A ADI (Analog Devices, Inc.) | 1 $86.9400 | Datasheet | 1.2A | 1, Non-Isolated | 35V | Dimmable | 6V ~ 27V | Board(s) | LTM8005 | 9,516 Cart + RFQ |
 DC1470A ADI (Analog Devices, Inc.) | 1 $294.2500 | Datasheet | 20A | 1, Non-Isolated | 4.5V | Dimmable | 6V ~ 36V | Board(s) | LT3743 | 8,036 Cart + RFQ |
 DC1511A-A ADI (Analog Devices, Inc.) | 1 $76.5000 | Datasheet | 1A | 1, Non-Isolated | 36V | PWM Brightness control | 3V ~ 30V | Board(s) | LTM8042 | 1,409 Cart + RFQ |
 DC2286A ADI (Analog Devices, Inc.) | 1 $176.5500 | Datasheet | 1A | 2, Non-Isolated | 8V | - | 9V ~ 36V | Board(s) | LT3932 | 7,744 Cart + RFQ |
 DC1784B ADI (Analog Devices, Inc.) | 1 $176.5500 | Datasheet | 1A | 3, Non-Isolated | 50V | Dimmable | 2.5V ~ 40V | Board(s) | LT3797 | 5,593 Cart + RFQ |
 DC2339A ADI (Analog Devices, Inc.) | 1 $176.5500 | Datasheet | 20A | 3, Non-Isolated | 6.05V | Dimmable | 5.5V ~ 36V | Board(s) | LT3744 | 3,737 Cart + RFQ |
 DC2345A ADI (Analog Devices, Inc.) | 1 $176.5500 | Datasheet | 2A | 1, Non-Isolated | 25V | - | 4V ~ 60V | Board(s) | LT8391 | 9,906 Cart + RFQ |
 MAX25608EVSYS# ADI (Analog Devices, Inc.) | 1 $386.7000 | Datasheet | 1.4A | 12, Non-Isolated | 3.7V ~ 6V | Dimmable | 4V ~ 60V | Board(s), Cable(s) | MAX25608 | 2,731 Cart + RFQ |
 DC1511A-B ADI (Analog Devices, Inc.) | 1 $76.5000 | Datasheet | 350mA | 1, Non-Isolated | 36V | PWM Brightness control | 3V ~ 30V | Board(s) | LTM8042-1 | 2,414 Cart + RFQ |
 DC1166A ADI (Analog Devices, Inc.) | 1 $88.2800 | Datasheet | 50mA | 1, Non-Isolated | - | - | 4.5V ~ 55V | Board(s) | LT3590 | 9,558 Cart + RFQ |
 DC1265A-A ADI (Analog Devices, Inc.) | 1 $100.0500 | Datasheet | 20mA | 18, Non-Isolated | - | Dimmable | 2.9V ~ 5.5V | Board(s) | LTC3220 | 2,504 Cart + RFQ |
 DC923A ADI (Analog Devices, Inc.) | 1 $117.7000 | Datasheet | 1.5A | 2, Non-Isolated | - | Dimmable | 4V ~ 36V | Board(s) | LT3475 | 7,966 Cart + RFQ |
 DC1288A ADI (Analog Devices, Inc.) | 1 $147.1200 | Datasheet | 200mA | 1, Non-Isolated | - | Dimmable | 8V ~ 16V | Board(s) | LT3496 | 3,280 Cart + RFQ |
 DC1405A ADI (Analog Devices, Inc.) | 1 $147.1200 | Datasheet | 61mA | 3, Non-Isolated | - | Dimmable | 3V ~ 30V | Board(s) | LT3492 | 2,593 Cart + RFQ |
 DC2361A ADI (Analog Devices, Inc.) | 1 $176.5500 | Datasheet | 330mA | 1, Non-Isolated | 43.5V | Dimmable | 8V ~ 28V | Board(s) | LT3952 | 2,125 Cart + RFQ |
 MAX16813EVKIT# ADI (Analog Devices, Inc.) | 1 $67.1100 | Datasheet | 150mA | 4, Non-Isolated | - | Short-Circuit Protection | 6.5V ~ 40V | Board(s) | MAX16813 | 5,470 Cart + RFQ |
 MAX25612BEVKIT# ADI (Analog Devices, Inc.) | 1 $87.4500 | Datasheet | 2A | 1, Non-Isolated | 3V ~ 48V | Dimmable | 6V ~ 18V | Board(s) | MAX25612 | 7,274 Cart + RFQ |
